Name: Westlock Rotary Position Monitors Limit Switch 2200 Series and 2600 Series for Fisher EZ valve
Brand: Westlock
SKU: 2200
Price: 1.00 USD
Availability: InStock
Rating: 4.5 (151 reviews)

Trang chủ > các sản phẩm > Phụ kiện van điều khiển >

Westlock Rotary Position Monitors Limit Switch 2200 Series and 2600 Series for Fisher EZ valve

Hàng hiệu:

Westlock

Model Number:

2200

Liên hệ chúng tôi

Yêu cầu báo giá

Westlock Rotary Position Monitors Limit Switch 2200 Series and 2600 Series for Fisher EZ valve

Thông tin chi tiết sản phẩm

Product name:

Westlock Rotary Position Monitors Limit Switch 2200 Series and 2600 Series for Fisher EZ valve

Model:

2600& 2200

Temp. range:

-30°C to +85°C

Brand:

Westlock

Shaft and hardware:

Stainless steel

Air supply:

0.2MPa~0.55MPa

Air consumption:

≤0.6NL/min

Travel:

10~100mm(60~90°)

Limit of intrinsic error:

±1.0%

Hysteresis error:

≤1.0%

Actuator:

Pneumatic

Coating:

Nickel Plated

Connection:

Threaded

Control:

Manual

Flow:

2.5 GPM

Frequency:

50Hz

Material:

Stainless Steel

Power:

2.5KW

Pressure:

1000 PSI

Size:

1/2 Inch

Temperature:

200 Deg C

Voltage:

220V

Warranty:

1 Year

Weight:

1.2KG

Sản phẩm liên quan

Các loại Fisher MR98L MR98H và MR98HH được sử dụng để giảm áp và van giảm chênh lệch làm bộ điều chỉnh áp suất

Nhận giá tốt nhất

van điều chỉnh điều chỉnh áp suất cao Tartarini Loại A100 điều chỉnh áp suất khí để gắn Skid

Nhận giá tốt nhất

Bộ điều chỉnh áp suất dòng ITRON B31 và van giảm áp suất khí để gắn trượt

Nhận giá tốt nhất

Tartarini R/73 Bộ điều chỉnh giảm áp suất van lò xo hai giai đoạn cho thiết bị đường ống

Nhận giá tốt nhất

Liên hệ chúng tôi

86-151-2102-3088

edward.zhao@gongboshi.com

Liên hệ ngay

Mô tả Sản phẩm

Specification

Series	2000
Model	2600 and 2000
Input signal	4～20mA analog signal or digit signal
Input impedance	250 ± 5% at 25℃
Characteristic	Linear
Brand Name	KOSO
Pilot valve	avaNon-bleeding type/Single acting and double acting types are available
Air supply	Output air pressure 50% Single acting type : 5Nl / min at 140 Kpa air supply Double acting type : 15Nl / min at 400 Kpa air supply
Max. capacity	Capacity when output is atmospheric venting. Single acting type : 175Nl / min at 140 Kpa air supply Double acting type :400Nl / min at 400 Kpa air supply
Performance	* Available with SPDT or DPDT switches. * Standard 6 m lead allows remote mounting if required. * Cable marked as appliance wiring material UL758. * Rhodium contact option for use with low power I/O’s for longer contact life. * Highly resistant to shock and vibration stresses, chemical and environmental exposure. * Integrated FieldSet trigger system permits easy calibration of position limits. * Standard 4’ (1.2m) lead accommodates mounting to large valve, with optional 20’ (6m) lead for more remote mounting
Air connection	Rc 1/4
Wiring connection	G 1/2
Ambient temperature	Standard type 20 80 High temperature service (option) 0 100 Low temperature service (option) 50 60
Ambient humidity range	10 90% RH
Enclosure	Weather proof type ( IP65 ) Explosion proof type ( Ex md CT6 ) 01171 Intrinsically safe explosion proof type ( Exia CT6 ) 01172
Standard anicillary	Auto-Manual change

FEATURES USABLE WITH LOW TO HIGH CAPACITY ACTUATORS By adjusting the built-in capacity control spring, the positioner can be made
optimum to the given actuator. A LOW AIR CONSUMPTION The pilot valve is low in air consumption and high in capacity. OUTPUT CHARACTERISTICS SELECTABLE Having a cam within the feedback construction, choices other than the standard linear characteristic are available. COMPATIBLE WITH VARIOUS FEEDBACK TYPES Applicable to the following types by simply exchanging the cam block. * For
Linear type actuator : Feedback for Standard lever type EP 8 1 * For Rotary type actuator : Feedback for lever type EP 8 2 * For
Rotary type actuator : Feedback for direct connection to driving shaft EP 8 4 REVERSE ACTION PILOT VALVE EASILY AVAILABLE The positioner for double acting actuators can be used as a reverse action pilot valve when combined with a spring return actuator that requires a reverse action pilot. ANTI-PRESSURE AND EXPLOSION PROOF STRUCTURE MARKING ON-SITE ADJUSTMENT POSSIBLE The anti-pressure and explosion proof construction, with the terminal and coil blocks enclosed together in one package, makes it possible to remove the positioner cover for inside inspection or span adjustment even in an explosive ambient. INTRINSICALLY SAFE
CONSTRUCTION FOR A WIDE SCOPE OF APPLICATIONS The intrinsically safe construction (torque-coil type: EP82) cover terminals and coil as one package. This, combined with The adoption of the specified zener barrier, makes the unit applicable in all hazardous gas location ( including Class 0 area) ranging from low ( 40 ) to high ( 60 ) temperature environment.
