The Rosemount 705 is a fully integrated, 4-20 mA vibration transmitter designed for continuous monitoring and protection of critical rotating machinery in industrial environments. Manufactured by Emerson, a global leader in automation technology, this device serves as a fundamental component of predictive maintenance strategies, converting raw mechanical vibration data into a standardized, actionable output signal. Its primary function is to provide a reliable and continuous indication of overall machine health, enabling operators and control systems to detect deteriorating conditions early and prevent catastrophic failures, unplanned downtime, and costly repairs.
Core Functionality and Measurement Principle
Unlike simple data collectors used for periodic analysis, the Rosemount 705 is permanently installed on assets like pumps, motors, fans, compressors, and gearboxes. It is engineered to measure and transmit a 4-20 mA analog signal that is directly proportional to the overall vibration amplitude. This amplitude is most commonly expressed as velocity, typically in units of mm/s or in/s RMS (Root Mean Square), which is a preferred measure for assessing machine health as it correlates well with the severity of vibration.
The transmitter operates by utilizing an internal piezoelectric accelerometer. This sensor generates an electrical charge when subjected to mechanical vibration. This raw signal is then integrated, conditioned, and processed within the robust electronics of the 705. The result is a highly accurate, noise-resistant 4-20 mA output, where 4 mA typically represents a "good" or "safe" vibration level (often zero or a low-scale value), and 20 mA represents the full-scale, "danger" level, which is user-configurable. This simple signal can be easily wired directly into a Distributed Control System (DCS), Programmable Logic Controller (PLC), or any other host system for real-time monitoring, alarm triggering, and even automated shutdown sequences.
Key Features and Design Advantages
The Rosemount 705 is renowned for its robustness and reliability, engineered to perform in the harsh conditions typical of industrial plants. Its housing is weatherproof and corrosion-resistant, typically rated NEMA 4X / IP66, ensuring protection against moisture, dust, and chemicals. A significant design feature is its two-wire operation. This means it requires only a single pair of wires for both power and signal transmission, drastically simplifying installation, reducing wiring costs, and making it compatible with standard infrastructure used for other 4-20 mA field instruments.
Another critical advantage is its ease of use and configuration. The device is often pre-programmed at the factory to specific parameters, but field configuration is straightforward using Emerson's AMS Trex device communicator or any other HART-compatible handheld. Through the HART (Highway Addressable Remote Transducer) protocol, users can set the measurement range (e.g., 0 to 25 mm/s RMS), check the current output value, perform a built-in self-test to verify sensor health, and even view the live vibration value digitally superimposed on the analog signal. This digital access provides a layer of diagnostic capability beyond the simple analog loop.
| Category | Details |
|---|---|
| Product Positioning | Fully integrated 4-20 mA vibration transmitter for continuous monitoring and protection of rotating machinery. Supports predictive maintenance strategies by converting vibration data into actionable signals. |
| Core Functionality & Measurement Principle | - Permanently installed on pumps, motors, fans, compressors, gearboxes.- Measures overall vibration amplitude (typically velocity, mm/s or in/s RMS).- Internal piezoelectric accelerometer generates charge under vibration → processed to stable 4-20 mA output.- 4 mA = safe/good condition, 20 mA = danger/full-scale level (user-configurable).- Output integrates directly into DCS/PLC for monitoring, alarms, or automated shutdowns. |
| Performance | - Accurate, noise-resistant 4-20 mA signal.- Configurable measurement range (e.g., 0–25 mm/s RMS).- Supports real-time condition monitoring with predictive maintenance value. |
| Construction & Materials | - Rugged housing, weatherproof & corrosion-resistant.- Rated NEMA 4X / IP66 for protection against moisture, dust, and chemicals.- Two-wire design (power + signal on one pair), simplifying installation and reducing wiring costs. |
| Diagnostics & Smart Features | - HART® protocol for digital communication.- Configuration via AMS Trex communicator or HART handheld.- Built-in self-test verifies sensor health.- View live vibration values digitally overlaid on analog signal.- Factory pre-programming with easy field configuration. |
| Applications & Strategic Value | - Applications: Pumps, motors, compressors, fans, gearboxes, critical rotating assets.- Industries: Oil & gas, petrochemical, power generation, water treatment, mining.- Strategic Benefits: - Detects incipient faults (imbalance, misalignment, bearing wear, lubrication issues). - Prevents catastrophic failures via alarms and shutdown triggers. - Reduces maintenance costs through predictive scheduling. - Enhances operational safety and equipment uptime. |
| Overall Advantages | - Continuous, reliable machinery health monitoring.- Simple integration into control systems.- Rugged and low-maintenance design.- Provides critical link between physical machine vibration and digital control infrastructure.- Backbone of predictive condition monitoring programs. |
Application and Strategic Value
The strategic value of the Rosemount 705 lies in its role in transitioning from reactive or scheduled maintenance to a predictive maintenance paradigm. By providing a continuous stream of vibration data, it allows plant personnel to:
Detect Incipient Problems: Identify issues like imbalance, misalignment, bearing wear, and lubrication problems long before they cause failure.
Prevent Catastrophic Failures: Set alarms within the control system to alert operators when vibration levels exceed pre-defined thresholds, allowing for intervention before a minor issue escalates.
Reduce Maintenance Costs: Enable maintenance to be planned and scheduled during normal shutdowns, avoiding emergency repairs and maximizing the productive uptime of critical assets.
Enhance Safety: Mitigate the risk of sudden, dangerous equipment failures that could pose safety hazards to personnel.
In summary, the Rosemount 705 Vibration Transmitter is more than just a sensor; it is a reliable and intelligent sentinel for machinery health. Its robust design, simple integration, and powerful diagnostic capabilities make it an essential tool for improving operational reliability, safety, and efficiency in industries such as oil and gas, petrochemical, power generation, water treatment, and mining. It provides the critical link between physical machine vibration and the digital control world, forming the backbone of any effective condition monitoring program.
