The Endress+Hauser Proline Promag P 300 is a fully hygienic electromagnetic flowmeter designed for pharmaceutical and biotech applications. With a PFA liner, polished Ra less than 0.38 µm, and full 3-A and EHEDG compliance, it ensures sterile, drainable measurement of WFI, buffers, and CIP fluids. The integrated Heartbeat Technology enables traceable in-situ verification per USP and FDA requirements. The Proline 300 transmitter features a hygienic stainless steel housing, touch display, and HART/Modbus communication. Ideal for batching, filling, and process analytics in GMP environments, it supports 21 CFR Part 11 compliance via FieldCare.
| Parameter | Specification |
|---|---|
| Measuring Principle | Electromagnetic |
| Size Range | DN 2 to DN 150 |
| Accuracy | ±0.2% o.r. ± 1 mm/s |
| Batch Accuracy | ±0.1% (with dosing control) |
| Process Temperature | -20°C to +150°C |
| Pressure Rating | PN 40 / ASME Cl 300 |
| Liner | PFA, polished |
| Outputs | 4-20 mA HART, Modbus RS485 |
| Protection | IP69K |
| Certifications | 3-A, EHEDG, FDA, USP Class VI |
Yes, with full drainability.
Yes, 150°C for 60 minutes.
Yes, Heartbeat meets USP and 21 CFR.
Ra less than 0.38 µm on wetted parts.
Yes, with ±0.1% batch accuracy.
Contact our team for inquiries about the Proline Promag P 300, pricing, or to schedule a demo:
