The Azbil AVP300 is the high-performance, high-flow version of the AVP300 series, specially developed for large actuators and severe-service applications. It provides an exceptional 1000 L/min air delivery while maintaining the same ultra-low 0.1 L/min steady-state consumption and full digital communication suite (HART 7, FOUNDATION Fieldbus, Profibus PA). Advanced diagnostics, one-button auto-tuning, and SIL 2/3 capability make it the ultimate solution for critical control loops on turbine bypass valves, compressor anti-surge, and large pipeline ESD service.
| Parameter | Specification |
|---|---|
| Model | AVP300-HP Series |
| Air Capacity | 1000 L/min (Sup) / 900 L/min (Exh) |
| Air Consumption | ≤0.1 L/min (steady) |
| Stroke | Linear up to 200 mm; Rotary up to 120° |
| Accuracy | ±0.5% F.S. |
| Temperature | -55°C to +85°C |
| Enclosure | IP66 / NEMA 4X, optional Ex d |
| Hazardous Area | ATEX, IECEx, FM, CSA (IS / Ex d / XP) |
| SIL Capability | SIL 2 standard, SIL 3 redundant |
| Weight | 4.5 kg (aluminum), 9.0 kg (316SS) |
1000 L/min – one of the highest in the market.
Yes, certified for SIL 3 in 1oo2 configuration.
Yes, 316SS housing and marine certifications available.
