The Rotork IQT3 is the world’s most advanced direct-drive quarter-turn electric actuator — no gearbox, no brake, no clutch. Using the same proven IQ3 Pro technology platform, it delivers torque from 50 to 3,000 Nm with speed options from 0.5 to 6 seconds per 90°. With absolute encoder, built-in data logger, Bluetooth® setting, and optional battery backup for fail-safe operation, the IQT3 is the ultimate solution for critical ball, butterfly, and plug valves in oil & gas, water, and power applications.
| Parameter | Specification |
|---|---|
| Torque Range | 50 – 3,000 Nm |
| Speed Range | 0.5 – 6 seconds per 90° |
| Power Supply | 110–690 VAC, 24–380 VDC, 1-phase & 3-phase |
| Enclosure | IP68 (10 m / 7 days), Ex db IIB/IIC T4/T6 |
| Communication | Pakscan, Profibus, Modbus, HART, FF, Ethernet |
| Duty Rating | IQT: S2-15 min, IQT-M: S4 1,200 starts/hour |
| Certification | SIL2/3, ATEX, IECEx, FM, CSA |
No — direct-drive design eliminates the need for a brake.
Yes — optional battery pack provides fail-safe positioning.
As fast as 0.5 seconds per 90° in IQT-F (fast) version.
