The Neles ND9000 is the only intelligent valve positioner specifically engineered for hygienic and aseptic processes. Featuring electropolished 316L stainless steel housing (Ra ≤ 0.4 µm), full drainability, and 3-A, EHEDG, FDA, and USP Class VI certifications, it ensures zero contamination risk in pharmaceutical, biotech, and high-purity food & beverage applications. Retaining all ND9000 diagnostics (valve signature, performance monitoring) and ultra-low air consumption, it is the preferred choice for diaphragm, angle seat, and butterfly valves in sterile service.
| Parameter | Specification |
|---|---|
| Model | ND9100H / ND9300H |
| Material | 316L stainless steel, electropolished |
| Surface Finish | Ra ≤ 0.4 µm internal, ≤ 0.8 µm external |
| Input Signal | 4–20 mA + HART 7 |
| Temperature Range | -20°C to +85°C (SIP +150°C) |
| Air Supply | Clean, dry instrument air |
| Protection | IP66 / IP67, NEMA 4X |
| Certifications | 3-A, EHEDG, FDA, USP Class VI, ATEX Ex ia |
Yes — designed for repeated 150°C steam sterilization.
Ra ≤ 0.4 µm internal, fully drainable design.
Yes — full ND9000 diagnostic suite including valve signature.
