In ammonia storage spheres, LPG bullets and small LNG tanks the FMP54 with coaxial probe is installed everywhere. The coaxial version has no dead zones and measures right to the bottom even with very low dielectric (εr ≥ 1.4). It handles the big temperature swings from filling cold product to warm ambient without losing signal. Many plants have been running the same FMP54 for 15+ years with zero maintenance.
| Media | Liquid ammonia, LPG, LNG, N2, CO2, etc. |
| Temperature range | -196 °C to +200 °C |
| Pressure range | vacuum to 100 bar |
| Probe type | Coaxial 42 mm (standard for ammonia) |
| Accuracy | ±2 mm |
Q: Will it work when the tank is cold and then warms up?
A: Yes – the ceramic coupling handles 400 K temperature shock without issues.
Q: Do I need a stilling well?
A: Not mandatory, but many customers use the coaxial probe inside existing stilling wells.
